ASTM D-2850
The Triaxial Test Set provides test Load up to 100kgf at any speed 0,00 mm to 5.00 mm per minute. This feature provides the capabilty for use in application such as constant rate of load and constant rate of stress. Measuring and single switch for loading or unloading of sample making it extremely easy to use. A moveable cross head allow a wide range of sample sizes to be tested with simple adjustment. Ideal for UU, CD and CU test version.
Part And Spesification qty
Triaxial electromotor 1000 kg capacity
Proving ring 200 kg capacity
Dial deformation 20 mm
Triaxial cell for sample 38 mm & 50 mm
Volume change
Pore water pressure
Vacuum pump
Water tank
Air compressor 8 kg/cm2 220 v
Sample preparation
Triaxial Compression Machine 1 ton Variable switch, hand operated and Motorized operated 220 v
Load Measuring 300 kgf ( include calibration certificate )
Displacement measuring Dial Gauge 30 x 0.01 mm
Control panel Assemblied measruing pore pressure 10 kg/cm2 digital system, Cell pressire 10 kg/cm2, Back pressure 10 kg/cm2 (Manometer system), Constant Pressure Unit Air Regulator, Bottom Water Tank, Vacuum Tank
Air Compressor 5 kg/cm2 220 v
O-Ring Placing tool 35 / 50 mm
Suction membrane device 35 / 50mm 1 pcTwo ways split former dia 35 / 50 mm
Sample Tube dia. 35 / 50 mm and extruder
Rubber membrane 35 / 50 mm
Membrane sealing ring 35 / 50 mm
Part And Spesification
Electricial loading machine Electric, 220 V-AC, 1/2 HP 1 phase, speed 0.05/min riversing switch
CBR Mold Machined steel 6 ” i.d 7 ” height 2 ” height of collar 3 pcs
pacer Dish Machined steel 5 -15/ 16 ” dia, 2.416 ” height 1 pc
Cutting Edge Machine steel, Sharp edge 1 pc
Circular Surcharge Weight Machine steel, S – 7/ 8 ” dia, 51 lbs weight 3 pcs
Slotted Surcharge Weight Machine steel, 5 – 7/ 8 ” dia, 51 lbs weight 3 pcs
Modified proctor hammer Machine steel, 18 ” drop height 10 lbs weight 1 pc
Swell Plate 3 pcs
Swell Tripot 3 pcs
kertas saring 1 box
Proving Ring 6000 lbs capacity 1 pc
Square Pan Galvanized steel 65 x 65 x 7.5 cm 1 pc
Tin Box Alumunium, 60 gr capacity 12 pcs
Graduated Cylinder 1000 ml capacity 1 pc
Scoop Cast Aluminium 1 pc
Trowel Pointed type 1 pc
Straight Edge 300 mm length 1 pc
